Omada 24-Port 100Mbps PoE Switch | TL-SL1226P
24× PoE+ 10/100 Mbps RJ45 ports, 2× Gigabit RJ45 ports, and 2× combo Gigabit SFP slots.
High PoE power budget with up to 30 W for each PoE port and 250 W for all PoE ports.*
Up to 250 m data and power PoE transmission range under Extend Mode**, ideal for surveillance system.
Priority Mode ensures high priority of ports 1–8 to guarantees the quality of sensitive applications like video monitor.
Isolation Mode allows one-click client traffic separation for higher security and performance.
PoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices.
Plug and play, with no configuration and installation needed
| Interface |
|
|---|---|
| Network Media |
|
| Fan Quantity | 2 Fans |
| Physical Security Lock | Yes |
| Power Supply | 100-240 VAC, 50/60 Hz |
| Packet Forwarding Rate | 6.54 Mpps |
| PoE Ports (RJ45) |
|
| Mac Address Table | 8 K |
| Jumbo Frame | 10 KB |
| Switching Capacity | 8.8 Gbps |
| Dimensions ( W x D x H ) | 17.3 × 7.1 × 1.7 in (440 × 180 × 44 mm) |
| Max. Power Consumption | 14.81 W (220/50 Hz. no PD connected) 302.88 W (220/50 Hz. with 250 W PD connected) |
| Max. Heat Dissipation | 50.35 BTU/h (no PD connected) 1029.79 BTU/h (with 250 W PD connected) |
| Advanced Features |
|
|---|---|
| Transmission Method | Store-And-Forward |
| Certification | CE, FCC, RoHS |
|---|---|
| Package Content |
|
| Environment |
|
This Product Specifications
Brand
Device Type
Switch Features
Switch Speed Type
Switch Port
Switch Uplink Port
Switch Uplink Type
PoE Standard
PoE Budget
Network Management
Power Type
Installation Environment
Highlight Spec
