Audio and Video

Video Input

4-channel IPC

Input/Output

Wireless Zone

Supports 150 wireless peripherals (6 sirens, 64 wireless keyfobs, 4 repeaters, 8 keypads, 8 PIR-Cameras)

Port

Network Port

1 × RJ-45 10 M/100 M Ethernet port

Network Mode

Ethernet, Wi-Fi and Cellular network (Supports installation of dual SIM cards. Only one card can be enabled at a time)

Storage Battery

Built-in lithium battery

Indicator Light

1 for multiple statuses (alarm, arming, disarming, networking, and malfunction)

Button

1 × reset, 1 × power, 1 × AP

Buzzer

Built-in

Function

Tamper Alarm

Yes

SMS

Yes (up to 5 phone numbers)

Calling Alarm

Yes (up to 5 phone numbers)

Video Linkage

Yes

Network Protocol

TCP/IP, including PPTP, L2TP, DHCP, UPNP, and NTP

Remote Upgrade

Cloud update

Arm and Disarm

App; keyfob; schedule

Power Failure Protection for Configured Parameters

Yes

User Management

Share function for App users

Cache

Max. 50 entries (ANR)

Low Battery Alarm

Yes

Search

Search for push messages, device status, and program version, and detect signal strength

Event Logs

Max. 5000

Wireless

Carrier Frequency

433.1 MHz–434.6 MHz

Transmitter Power (EIRP)

Limit 10 mW

Communication Distance

Up to 1,200 m (3,937.01 ft) in an open space

Communication Mechanism

Two-way

Encryption Mode

AES128

Frequency Hopping

Yes

Wi-Fi

Wi-Fi Standard

IEEE 802.11b/g/n

Wi-Fi Frequency Range

2400-2483.5 MHz

Wi-Fi Power Transmission

≤20 dBm@2400-2483.5 MHz

Cellular Network

Cellular Network Standard

GSM/WCDMA/LTE

Frequency Range

EU:
4G: FDD-LTE: B1/B3/B7/B8/B20; TDD-LTE: B38/B40/B41;
3G: WCDMA: B1/B5/B8;
2G: GSM: 1,800/900 MHz;
LM:
4G: FDD-LTE: B1/B2/B3/B4/B5/B7/B8/B28; TDD-LTE: B40;
3G: WCDMA: B1/B2/B5/B8;
2G: GSM: 850/900/1800/1900 MHz

Transmitter Power (EIRP)

EU:

4G: Power class3: 23 dBm±2 dB

3G: Power class3: 24 dBm+1/-3 dB

2G: Power class0: 30 dBm±3 dB (GSM900)

Power class5: 33 dBm±3 dB (GSM1800)

LM:

4G: Power class3: 23 dBm±2 dB

3G: Power class3: 24 dBm+1/-3 dB

2G: Power class0: 30 dBm±3 dB (GSM850/900)

Power class5: 33 dBm±3 dB (GSM1800/1900)

General

Power Supply

12 V DC, 1.5 A (Europe, UK and USA power adapters are optional)

Operating Temperature

–10 °C to +50 °C (+14 °F to +122 °F) (indoor)

Operating Humidity

10%–90% (RH)

Product Dimensions

163.0 mm × 163.0 mm × 32.0 mm (6.42" × 6.42" × 1.26") (L × W × H)

Packaging Dimensions

219.0 mm × 187.0 mm × 91.0 mm (8.62" × 7.36" × 3.58") (L × W × H)

Installation

Wall mount; Desktop

Net Weight

0.38 kg (0.84 lb)

Gross Weight

0.8 kg (1.76 lb)

Certifications

CE; FCC

Casing

PC + ABS

Battery Life

Storage battery standby for 12 hours
