FingerTec TimeLine 100
It is time to scrap the outdated manual punch card system and adopt an efficient RFID card time attendance system with TimeLine 100, specifically designed for office use. Simple to install and manage, TimeLine 100 offers large storage capacity, which is able to match office of various sizes especially when paired with TCMS V3, a Windows-based time attendance software complete with various reports for attendance management. On top, TimeLine 100 easily integrates with other FingerTec terminals in one centralized system as long as they have a card feature, allowing for customization within a workplace
Get up to 10,000 card templates and 30,000 transaction logs – more than enough to fulfill the requirements of an SME.
TimeLine 100 comes with the latest PUSH technology, suitable for FCC data storage and convenient for TimeTec TA. The technology eliminates the need for manual data download process.
|Manage Data Easily
TCMS V3 is loaded with useful features complete with various reports for your business. Its data integration to 3rd party software is made available through the readily available SDK.
|Combine Verification Methods
Opt for the combination of verification methods to secure your workplace further. Choose the card and password verification with the TimeLine 100 for tighter security.
Let your staff experience more independence by reporting their whereabouts via our workcodes feature.
|Data Management Simplified
TimeLine 100 is equipped with TCP/IP connectivity and when that is not available, a USB flash port can be used to transfer transaction logs into your computer.
|Short Message Display
Communicate with your employee by personalizing a short message to be displayed at the terminal when they verify. The message can be directed to an individual or to a group of staff.
|Value for Money
This model was designed to be economical so that you are able to implement FingerTec solutions at a lower cost. We believe that when it comes to security, there should be no compromise.
|for illustration only * optional|
|SURFACE FINISHING||Acrylonitrile butadiene styrene (ABS)|
|TYPE OF ANTENNA||RFID|
|MEMORY||8 MB flash memory & 32 MB SDRAM|
|ALGORITHM||BioBridge VX 9.0|
|PRODUCT DIMENSION (L X W X H), mm||190 x 50 x 140|
|ENROLLMENT & VERIFICATION|
|• Methods||Card & password|
|• Card per user ID||1|
|• Reading distance, mm||40 ~ 80 (RFID, HID), 30 ~ 50 (Mifare)|
|• Verification time (sec)||< 1|
|• RFID: 64-bit, 125kHz, RF output power (EN300-330)||Yes|
|• MIFARE: MFIS50/S70, 13.56MHz||Make to order|
|• HID: HID 1325, 26-bit, 125kHz||Make to order|
|• Method||TCP/IP, USB disk (Optional: RS232 & RS485)|
|• Baud rates||9600, 19200, 38400, 57600, 115200|
|• Temperature (°C)||0 ~ 45|
|• Humidity (%)||20 ~ 80|
|• Power input||DC 5V 2A|
|• Siren||Buit in and external|
|• Work codes||Yes|
|• Display||Black and white|
|• Short messaging||Yes|
|VOICE / DISPLAY LANGUAGE (TERMINAL)||English (Standard), Arabic, Indonesian, Chinese (Simplified), Cantonese / Chinese (Traditional), Thai, Vietnamese, Spanish, Portuguese (Portugal), French, Russian, German, Turkish & Persian
Other languages are available upon request.
|SOFTWARE LANGUAGE||Arabic, Bulgarian, Chinese (Simplified), Chinese (Traditional), English, German, Hindi, Indonesian, Kurdish, Malay, Portuguese, Russian, Spanish, Thai, Vietnamese|
